| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
HONDA
31100-PLM-A01, 31100PLMA01, 31100-PLM-A02, 31100PLMA02, 31100-RJH-004, 31100RJH004, AHGA50, AHGA51, AHGA64
MITSUBISHI
A005TA6991, A005TA6991A, A005TA7091, A005TA7091ZC, A005TA7091ZE, A005TA7191, A005TA7191ZC, A5TA6991, A5TA6991A, A5TA7091, A5TA7091ZC, A5TA7091ZE, A5TA7191, A5TA7191ZC |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Belt Pulley Ø [mm] 63
Clamp B+ / IG / C / L / FR
Exchange Part
Fastening Type 3-point attachment
Number of ribs 6
Position/Degree L 38
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 6,32
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
MITSUBISHI
30A6800101, 30A6800800, 30A6800801, 38A6800800, A001T24771, A007TA0171, A007TA0171B, A007TCA0271, A007TCA271, A007TCA271AM, A1T24771, A7TA0171, A7TA0171B, A7TCA0271, A7TCA271, A7TCA271AM, MM409651
SCHAEFF
5527658958, 5999999924
VOLVO
7417082
WEIDEMANN
1000198601, 1000299651 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 40
Belt Pulley Ø [mm] 74
Distance from belt pulley to alternator [mm] 42
Number of grooves 1
Number of mounting bores 2
Print a label without applications Yes
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
MERCEDES-BENZ
008 154 96 02, 009 154 41 02, A 008 154 96 02, A 009 154 41 02 |
| |
|
| |
DAEWOO
KORANDO
MERCEDES-BENZ
190, C-CLASS, CLK, Combi, COUPE, E-CLASS, G-CLASS, O 100, Sedan, SPRINTER, T1, T1/TN
SSANGYONG
KORANDO, MUSSO |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Belt Pulley Ø [mm] 56
Distance from belt pulley to alternator [mm] 101
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+W
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
MERCEDES-BENZ
0101540802, 010154080280, 101540802, 10154080280, A0101540802, A010154080280 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 90
Belt Pulley Ø [mm] 56
Clamp B+ / D+
Exchange Part
Fastening Type 002
Number of ribs 6
Position/Degree L 60
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 6,15
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
DAF
1516533R
SCANIA
1117252, 257592, 354858, 357736, 371972, 410676, 571505, 571506 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 55
Connecting thread M16-17
Number of mounting bores 2
Plug Type ID B+D+W
Pulleys without belt pulley
Rotation Direction Anticlockwise rotation, Clockwise rotation
Specification N1
Voltage [V] 28
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
