| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
BMW
12 31 7 550 319, 12317550319, 7 550 319, 7550319
MINI
12 31 7 550 224, 12317550224, 12 31 7 550 319, 12317550319, 12 31 7 550 997, 12317550997, 12 31 7 559 223, 12317559223, 7 550 224, 7550224, 7 550 319, 7550319, 7 550 997, 7550997, 7 559 223, 7559223 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 110
Belt Pulley Ø [mm] 48
Clamp M8
Exchange Part
Fastening Type 3-point attachment
Number of ribs 6
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 5,97
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
98 056 439, R1 530 090
HITACHI
LR111 0503, LR1110-503A, LR1110-503B, LR1110-503C, LR1110-503D, LR1110-503E, LR1110-503F
ISUZU
8-97363-832-0, 8-97363-832-1, 8-97363-832-2, 8-97363-833-0, 8-97363-833-1, 8-98056-439-0
OPEL
62 04 198, 62 04 252, 93 189 496, 93 189 502, 95 62 189, 97 363 832, 97 363 833, 98 056 439 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 110
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 60
Distance from belt pulley to alternator [mm] 44
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+LF
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
HITACHI
LR1110-503, LR1110-503A, LR1110-503A-F, LR1110-503B, LR1110-503C, LR1110-503D, LR1110-503E, LR1110-503F
ISUZU
8973638320, 8973638321, 8973638322, 8980564390
OPEL
1204618, 6204197, 6204252, 93189496, 97363832, 98056439
VAUXHALL
93189496, 95520888, 97363832, 98056439, R1530090 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 110
Belt Pulley Ø [mm] 60
Clamp B+
Exchange Part
Fastening Type 3-point attachment
Number of ribs 6
Position/Degree L 18
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 7,93
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
TOYOTA
27060-21010, 27060-21011, 27060-21040, 27060-21041, 27060-33010 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Belt Pulley Ø [mm] 57
Distance from belt pulley to alternator [mm] 38
Number of grooves 4
Number of mounting bores 3
Plug Type ID B+MIGL
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
TOYOTA
27060-21010, 2706021010, 27060-21011, 2706021011, 27060-21040, 2706021040, 27060-21041, 2706021041, 27060-33010, 2706033010 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Belt Pulley Ø [mm] 60
Clamp B+
Exchange Part
Fastening Type 3-point attachment
Number of ribs 4
Position/Degree R 20
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 5,375
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
