| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
AUDI
04L903021D, 04L903021DX, 04L903021H, 04L903021L, 04L903023K, 04L903023KX, 04L903023L, 04L903023LX, 4L903021D, 4L903021DX, 4L903021H, 4L903021L, 4L903023K, 4L903023KX, 4L903023L, 4L903023LX
SEAT
04L903021D, 04L903021DX, 04L903021H, 04L903023K, 04L903023KX, 04L903023L, 04L903023LX, 4L903021D, 4L903021DX, 4L903021H, 4L903023K, 4L903023KX, 4L903023L, 4L903023LX
SKODA
04L903021D, 04L903021DX, 04L903021H, 04L903023K, 04L903023KX, 04L903023L, 04L903023LX, 4L903021D, 4L903021DX, 4L903021H, 4L903023K, 4L903023KX, 4L903023L, 4L903023LX
VW
04L903021D, 04L903021DX, 04L903021H, 04L903021L, 04L903023K, 04L903023KX, 04L903023L, 04L903023LX, 4L903021D, 4L903021DX, 4L903021H, 4L903021L, 4L903023K, 4L903023KX, 4L903023L, 4L903023LX |
| |
|
| |
AUDI
A3, A3 Sportback, Q2, Q3, Q3 Sportback
SEAT
ALHAMBRA, ARONA, ATECA, IBIZA, LEON, TARRACO
SKODA
KAROQ, KODIAQ, OCTAVIA, SUPERB
VW
ARTEON, ARTEON SHOOTING BRAKE, GOLF, GOLF ALLTRACK, GOLF SPORTSVAN, PASSAT, PASSAT ALLTRACK, POLO, SHARAN, T-CROSS, TIGUAN, TOURAN, T-ROC |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 140
Belt Pulley Ø [mm] 52
Clamp M8 B+
Number of grooves 6
Plug Type ID LIN/COM
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
AUDI
03L903017, 03L903017E, 03L903017EX, 03L903017X, 04L 903 017, 04L 903 017 E
SEAT
03L903017, 03L903017E, 03L903017EX
SKODA
03L903017, 03L903017E, 03L903017EX
VW
03L903017, 03L903017E, 03L903017EX, 03L 903 017 X, 04L 903 017, 04L 903 017 E |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 50
Clamp COM/LIN2-D, M8 B+
Number of grooves 6
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 55
Clamp COM/LIN2
Number of grooves 7
Number of mounting bores 2
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 55
Clamp B+ / com
Exchange Part
Fastening Type 3-point attachment
Number of ribs 7
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 6,605
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
VAG
03N903023BX, 03N903023CX
VW
03N903023B, 03N903023BX, 03N903023C, 03N903023CX |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 49
Number of grooves 6
Plug Type ID LIN/COM
Pulleys with belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
