| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 030 093
HITACHI
LR17-0505, LR170 505A, LR170 505B, LR170 505C, LR170 505D, LR170 505E, LR17-0511, LR170 511A, LR170 511B
ISUZU
8-97150-200-0, 8-97150-200-1, 8-97241-021-0
OPEL
62 04 042, 62 04 046, 62 04 106, 90 371 767, 90 371 769, 95 12 038, 97 150 200, 97 241 021 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 84
Belts Without V-belt
Distance from belt pulley to alternator [mm] 42
Number of grooves 1
Number of mounting bores 2
Plug Type ID B+L,W
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
OPEL
10480409, 24439410, 3493823, 3493824, 6204000, 6204002, 6204151, 95520882 |
| |
|
| |
CHEVROLET
CORSA
OPEL
ASTRA, CALIBRA, COMBO, CORSA, FRONTERA, OMEGA, TIGRA, VECTRA
VAUXHALL
ASTRA, CALIBRA, CAVALIER, FRONTERA, OMEGA, VECTRA |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 100
Belt Pulley Ø [mm] 50
Distance from belt pulley to alternator [mm] 60
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
LAND ROVER
AMR 4248, YLE 10113, YLE 1013 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 100
Belt Pulley Ø [mm] 49
Distance from belt pulley to alternator [mm] 40
Number of grooves 7
Number of mounting bores 2
Plug Type ID B+D+W
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
CITROËN
5701 A9, 5705 7J, 5705 7K, 5705 E8, 5705 GR, 5705 HZ, 5705 L3, 5705 P7, 5705 S1
CITROËN/PEUGEOT
5701 A9, 5705 7J, 5705 7K, 5705 E8, 5705 GR, 5705 HZ, 5705 L3, 5705 P7, 5705 S1
FIAT
1323249080, 9616863280
MITSUBISHI
A004TA0091, A4TA0091
PEUGEOT
5701 A9, 5705 7J, 5705 7K, 5705 E8, 5705 GR, 5705 HZ, 5705 L3, 5705 P7, 5705 S1 |
| |
|
| |
CITROËN
C4 GRAND PICASSO, C4 PICASSO, DS4, EVASION, JUMPER, XANTIA, XM, XSARA
FIAT
DUCATO, ULYSSE
LANCIA
ZETA
PEUGEOT
306, 4007, 405, 406, 605, 806, BOXER, EXPERT |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 120
Belt Pulley Ø [mm] 56
Distance from belt pulley to alternator [mm] 52
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 85
Belt Pulley Ø [mm] 60
Distance from belt pulley to alternator [mm] 56
Number of grooves 5
Number of mounting bores 2
Plug Type ID B+D+
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
