| STARTER |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
GX73-11001-EC
JAGUAR
C2D36864, FW93-11001-AB, GX73-11001-EB, T2H3246 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Clamp Pin 30 M8 B+, Pin 50 M6
Flange Diameter [mm] 62
Number of mounting bores 2
Number of Teeth 11
Number of threaded holes 1
Pinion Rest Position [mm] 32,5
Rated Power [kW] 1,7
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
HYUNDAI
36100-03701, 36100-03706 |
| |
|
| |
HYUNDAI
i30, i30 CW, i30 Hatchback Van, i30 Kombi Van
KIA
CEE`D SPORTSWAGON, CEED, CEE'D, CEED SPORTSWAGON, PRO CEE´D, PROCEED, PROCEED Combi Van, RIO, STONIC, XCEED, XCEED Van |
| |
|
|
|
|
|
|
| |
| |
Article Information
Clamp M8 B+, Plug
Flange Diameter [mm] 75
Number of mounting bores 2
Number of Teeth 13
Number of threaded holes 2
Pinion Rest Position [mm] 14
Rated Power [kW] 1,2
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
GJ32-11001-AD, GJ32-11001-AE
JAGUAR
J9C1876
LAND ROVER
LR070686, LR085507 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Clamp M8 B+
Flange Diameter [mm] 70
Number of mounting bores 2
Number of Teeth 13
Pinion Rest Position [mm] 24
Rated Power [kW] 1,9
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Clamp Pin 30 M8 B+, Pin 50 M6
Flange Diameter [mm] 76
Number of mounting bores 3
Number of Teeth 12
Number of threaded holes 3
Pinion Rest Position [mm] 27
Rated Power [kW] 1,4
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
2101924, H1BT-11000-DB |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Clamp Pin 30 M8 B+, Pin 50 M6
Net weight [kg] 2,8
Number of mounting bores 3
Number of Teeth 11
Number of threaded holes 2
Pinion Rest Position [mm] 14
Rated Power [kW] 1,4
Rotation Direction Clockwise rotation
Voltage [V] 12
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
