| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
LEXUS
27060-38050
TOYOTA
2706038050 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 59
Bore Diameter 1 [mm] 10,1
Bore Diameter 2 [mm] 10
Clamp IG-S-L-M, M8 B+
Number of grooves 8
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 55
Clamp B+ / com
Exchange Part
Fastening Type 3-point attachment
Number of ribs 7
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 6,605
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
VW
03N903023B, 03N903023BX, 03N903023C, 03N903023CX, 3N903023B, 3N903023BX, 3N903023C, 3N903023CX |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 51
Clamp B+
Exchange Part
Fastening Type Four-point attachment
Number of ribs 6
Position/Degree R 90
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 7,492
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
MITSUBISHI
A002TN1199, A002TN1199A, A002TN1199AT, A002TN1199ZT, A003T15099, A003TN0399, A003TN0499, A2TN1199, A2TN1199A, A2TN1199AT, A2TN1199ZT, A3T15099, A3TN0399, A3TN0499, MD306834, MD313940, MD313942, MD327514, MD366051 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 75
Belt Pulley Ø [mm] 77
Clamp B+ S / L
Exchange Part
Fastening Type 3-point attachment
Number of ribs 2
Position/Degree R 30
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Supplementary Article/Supplementary Info 2 with pump
Voltage [V] 14
Weight [kg] 6,71
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
TOYOTA
27060-0Q200, 270600Q200 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 90
Belt Pulley Ø [mm] 61
Clamp B+ / com
Exchange Part
Fastening Type 3-point attachment
Number of ribs 6
Position/Degree L 8
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 4,82
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
