| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
CHRYSLER
56005684, 56005685, 56005685AB |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 75
Belt Pulley Ø [mm] 57
Clamp M6
Number of grooves 6
Rotation Direction Clockwise rotation
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
AUDI
054903015F, 078903016A |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 90
Belt Pulley Ø [mm] 64
Bore Diameter 1 [mm] 10
Clamp M8
Number of grooves 6
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
AUDI
059903019L, 059903019LX
VW
059903018Q, 059903018QX |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 56
Bore Diameter 1 [mm] 8,5
Clamp COM/LIN2, M8 B+
Number of grooves 6
Pulleys with freewheel belt pulley
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
AUDI
059903017P, 059903017PX, 059903018Q, 059903018QX, 059903018R, 059903018RX, 059903019L, 059903019LX, 59903017P, 59903017PX, 59903018Q, 59903018QX, 59903018R, 59903018RX, 59903019L, 59903019LX
HITACHI
LR118-0856, LR118-0857
PORSCHE
059903018Q, 059903019L, 59903018Q, 59903019L |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 57
Clamp B+
Exchange Part
Fastening Type Four-point attachment
Number of ribs 6
Position/Degree R 90
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 7,67
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 90
Belt Pulley Ø [mm] 60
Bore Diameter 1 [mm] 10,5
Clamp M8
Number of grooves 8
Rotation Direction Clockwise rotation
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
