| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
VW
03L 903 023 B, 03L 903 023 BX, 03L 903 023 D, 3L9 030 23B, 3L9 030 23B X, 3L9 030 23D, VW |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 56
Distance from belt pulley to alternator [mm] 48,5
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+LIN
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
VW
06A 903 023 F, 06A 903 023 FX, 06J 903 023 P, 06J 903 023 PX, 6A9 030 23F, 6A9 030 23F X, 6J9 030 23P, 6J9 030 23P X |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 56
Distance from belt pulley to alternator [mm] 38
Number of grooves 6
Number of mounting bores 4
Plug Type ID B+LDF
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
VW
059903019D, 059903023K, 059903023KX, 059903023M, 059903023MX |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Belt Pulley Ø [mm] 56
Distance from belt pulley to alternator [mm] 38
Extended description OEM
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+LIN
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
CITROËN
16 068 569 80, 16 090 160 80, 16 112 857 80, 16 128 170 80, 16 482 360 80, 5702 J4, 5705 KR, 96 640 742 80, 96 780 494 80, 96 780 584 80, 98 037 509 80, 98 105 271 80
CITROËN/PEUGEOT
16 068 569 80, 16 090 160 80, 16 112 857 80, 16 128 170 80, 5702 J4, 5705 KR, 96 640 742 80, 96 780 494 80, 96 780 584 80, 98 037 509 80, 98 105 271 80
PEUGEOT
16 068 569 80, 16 090 160 80, 16 112 857 80, 16 128 170 80, 5702 J4, 5705 KR, 96 640 742 80, 96 780 494 80, 96 780 584 80, 98 037 509 80, 98 105 271 80 |
| |
|
| |
CITROËN
BERLINGO, C3, C3 AIRCROSS, C4, C4 GRAND PICASSO, C4 GRAND SPACETOURER, C4 PICASSO, C4 PICASSO II Van, C4 SPACETOURER, C5, C8, DS4, DS5, JUMPY, SPACETOURER
DS
DS 4, DS 5
FIAT
SCUDO
PEUGEOT
207, 3008, 308, 407, 5008, 5008 I Van, 508, 807, 807 Van, EXPERT, PARTNER, RIFTER, TRAVELLER
TOYOTA
PROACE, PROACE VERSO |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Article number of recommended accessories ZN5800
Belt Pulley Ø [mm] 54
Distance from belt pulley to alternator [mm] 51
Extended description OEM
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+COM
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
CITROËN
16 068 569 80, 16 090 160 80, 16 112 857 80, 16 128 170 80, 16 482 360 80, 5702 J4, 5705 KR, 96 640 742 80, 96 780 494 80, 96 780 584 80, 98 037 509 80, 98 105 271 80
CITROËN/PEUGEOT
16 068 569 80, 16 090 160 80, 16 112 857 80, 16 128 170 80, 5702 J4, 5705 KR, 96 640 742 80, 96 780 494 80, 96 780 584 80, 98 037 509 80, 98 105 271 80
PEUGEOT
16 068 569 80, 16 090 160 80, 16 112 857 80, 16 128 170 80, 5702 J4, 5705 KR, 96 640 742 80, 96 780 494 80, 96 780 584 80, 98 037 509 80, 98 105 271 80 |
| |
|
| |
CITROËN
BERLINGO, C3, C3 AIRCROSS, C4, C4 GRAND PICASSO, C4 GRAND SPACETOURER, C4 PICASSO, C4 PICASSO II Van, C4 SPACETOURER, C5, C8, DS4, DS5, JUMPY, SPACETOURER
DS
DS 4, DS 5
FIAT
SCUDO
PEUGEOT
207, 3008, 308, 407, 5008, 5008 I Van, 508, 807, 807 Van, EXPERT, PARTNER, RIFTER, TRAVELLER
TOYOTA
PROACE, PROACE VERSO |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 180
Article number of recommended accessories ZN5800
Belt Pulley Ø [mm] 54
Distance from belt pulley to alternator [mm] 51
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+COM
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
