| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 530 037
HITACHI
LR110 0502, LR1100-502A, LR1100-502B, LR1100-502C, LR1100-502E, LR1100-502F, LR1100-502G, LR1100-502H, LR1100-502J, LR1100-502K, LR1100-502L, LR1100-502N, LR1100-504B, LR1100-504C, LR1100-504E, LR110 0505, LR1100-505B
HONDA
31100-PLZ-D00, 31100PLZD00
ISUZU
8-97189-113-0, 8971891130, 8-97189-113-3, 8971891133, 8-97189-113-4, 8971891134, 8-97189-113-5, 8971891135, 8-97189-113-6, 8971891136, 8-97189-113-7, 8971891137, 8-97189-113-8, 8971891138, 8-97189-113-9, 8971891139, 8-97287-392-3, 8972873923, 8-97287-392-4, 8972873924, 8-97326-180-1, 8973261801, 8-98054-255-0, 8980542550, 8-98056-867-0
OPEL
12 04 158, 1204158, 62 04 140, 6204140, 6204284, 93 175 799, 93175799, 93 175 944, 93175944, 95 12 785, 97 189 113, 97189113, 98056867
VAUXHALL
93175799, 9512785, 97189113, 98056867, R1530037 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 100
Belt Pulley Ø [mm] 60
Clamp B+
Exchange Part
Fastening Type 3-point attachment
Number of ribs 6
Position/Degree L 18
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 7,52
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 030 072
HITACHI
LR17-0420, LR170 420B, LR170-427, LR170-427B, LR170-427C
ISUZU
8-97041-790-0
OPEL
12 04 144, 62 04 059, 90 542 407, 91 63 941, 95 12 124, 97 041 790 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 83
Belts Without V-belt
Distance from belt pulley to alternator [mm] 41
Number of grooves 1
Number of mounting bores 2
Plug Type ID B+SLNIG
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 030 093
HITACHI
LR17-0505, LR170 505A, LR170 505B, LR170 505C, LR170 505D, LR170 505E, LR17-0511, LR170 511A, LR170 511B
ISUZU
8-97150-200-0, 8-97150-200-1, 8-97241-021-0
OPEL
62 04 042, 62 04 046, 62 04 106, 90 371 767, 90 371 769, 95 12 038, 97 150 200, 97 241 021 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 84
Belts Without V-belt
Distance from belt pulley to alternator [mm] 42
Number of grooves 1
Number of mounting bores 2
Plug Type ID B+L,W
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Belt Pulley Ø [mm] 80
Clamp B+
Exchange Part
Fastening Type 3-point attachment
Number of ribs 1
Position/Degree L/R 0
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 6,76
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
OPEL
10480409, 24439410, 3493823, 3493824, 6204000, 6204002, 6204151, 95520882 |
| |
|
| |
CHEVROLET
CORSA
OPEL
ASTRA, CALIBRA, COMBO, CORSA, FRONTERA, OMEGA, TIGRA, VECTRA
VAUXHALL
ASTRA, CALIBRA, CAVALIER, FRONTERA, OMEGA, VECTRA |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 100
Belt Pulley Ø [mm] 50
Distance from belt pulley to alternator [mm] 60
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
