| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
RENAULT
50 00 725 698, 50 01 014 178, 50 01 014 181, 60 06 000 076, 77 00 714 313, 77 01 352 125, 77 01 362 052, 77 01 381 535 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 75
Connecting thread M17-17
Number of mounting bores 2
Plug Type ID B+,+L
Pulleys without belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
MERCEDES-BENZ
006 154 87 02, 006 154 89 02, 007 154 33 02, 007 154 34 02, 007 154 48 02, 007 154 52 02, 007 154 60 02, 007 154 61 02, 008 154 89 02, A 006 154 87 02, A 006 154 89 02, A 007 154 33 02, A 007 154 34 02, A 007 154 48 02, A 007 154 52 02, A 007 154 60 02, A 007 154 61 02, A 008 154 89 02 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 55
Belt Pulley Ø [mm] 55
Distance from belt pulley to alternator [mm] 101
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
MERCEDES-BENZ
0061543003, 0061548702, 0061548802, 0061548902, 0071543302, 0071543402, 0071544802, 0071545202, 007154520280, 0071545402, 007154540280, 0071546002, 007154600280, 0071546102, 007154610280, 0081548902, 008154890280, 61543003, 61548702, 61548802, 61548902, 71543302, 71543402, 71544802, 71545202, 7154520280, 71545402, 7154540280, 71546002, 7154600280, 71546102, 7154610280, 81548902, 8154890280, A0061543003, A0061548702, A0061548802, A0061548902, A0071543302, A0071543402, A0071544802, A0071545202, A007154520280, A0071545402, A007154540280, A0071546002, A007154600280, A0071546102, A007154610280, A0081548902, A008154890280 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 55
Belt Pulley Ø [mm] 55
Clamp B+ / B+ / D+
Exchange Part
Fastening Type 002
Number of ribs 6
Position/Degree L 60
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 5,11
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FIAT
116 76 05 060 00, 116 76 05 061 00, 4152101, 4152612, 4174626, 4242730, 4263584, 4263983, 4285622, 4474903, 4474904, 46231758, 46231786, 4711700, 4720511, 4721587, 47 215 89, 4721591, 4721592, 4731839, 4750583, 4799364, 4800504, 4808502, 48 085 03, 48 085 05, 4808507, 4849157, 77028550, 77138410, 77452410, 77515411, AT 05 060 01 08
IVECO
4808502, 4808507, 99461495
VM
3.852.2236F |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 55
Belt Pulley Ø [mm] 90
Belts Without V-belt
Distance from belt pulley to alternator [mm] 49
Number of grooves 1
Number of mounting bores 2
Plug Type ID B+D+
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FIAT
46231670, 46412678, 46430527 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 65
Belt Pulley Ø [mm] 62
Distance from belt pulley to alternator [mm] 54
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
