| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
1764817, 1821291, 2415010, CV6T-10300-DB, CV6T-10300-DC, RMCV6T-10300-DC |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 49
Bore Diameter 1 [mm] 8,5
Clamp COM/LIN1 PLUG 206, Pin 30 M8 B+
Distance from belt pulley to alternator [mm] 52
Manufacturer Restriction Always Cross by OE
Net weight [kg] 5,7
Number of grooves 6
Plug Type ID 0213
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
1764817, 1821291, CV6T-10300-DB, CV6T10300DB, CV6T-10300-DC, CV6T10300DC |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 49
Clamp B+ / com
Exchange Part
Fastening Type Four-point attachment
Number of ribs 6
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
Weight [kg] 6,28
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
104211-9540, 2198947, 2320081, JX6T-10300-FA, JX6T10300FA, LX6T-10300-EAA, MS1042119540 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 150
Belt Pulley Ø [mm] 52
Clamp COM/LIN2, M8 B+
Number of grooves 6
Plug Type ID 0213
Pulleys with freewheel belt pulley
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
HONDA
31100-5PA-A01, CSP71 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 135
Alternator Type for direct current generator
Article number of recommended accessories ZN5767
Belt Pulley Ø [mm] 58
Clamp LIN, M8 B+
Length 1 [mm] 39,5
Length 2 [mm] 25
Length 3 [mm] 36,5
Number of ribs 7
Plug Type ID 0311
Pulleys with freewheel belt pulley
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 12, 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
FORD
2179006, 2200625, 2449470, JX6T-10300-KA, JX6T-10300-KA02, JX6T-10300-KB, JX6T-10300-KC |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 165
Article number of recommended accessories ZN5807
Belt Pulley Ø [mm] 54
Clamp COM/LIN2C, Pin 30 M8 B+
Cooling Type air-cooled
Distance from belt pulley to alternator [mm] 56
Manufacturer Restriction Always Cross by OE
Net weight [kg] 7,3
Number of ribs 6
Plug Type ID 0213
Pulleys with freewheel belt pulley
Vehicle Main Current for vehicles with 12V main current
Voltage [V] 14
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
