| ALTERNATOR |
| |
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
LAND ROVER
AUU 1053, AUU 1184, RTC 5846, YLE 101560, YLE 101700
PERKINS
2871 A 142, 2871 A 161
ROVER
24161, 24198, 24219, 24228, 24241, ADU 1148, YLE 10019 |
| |
|
| |
AUSTIN
MONTEGO
FORD
CAPRI, ESCORT, ESCORT '81 EXPRESS, ESCORT '86 EXPRESS, FIESTA, ORION, P 100, SCORPIO, SIERRA, TAUNUS, TAUNUS '80, TRANSIT
LAND ROVER
RANGE ROVER
LDV
FREIGHT ROVER SHERPA, SHERPA
MG
MAESTRO
ROVER
100, 200, 400, MAESTRO, MONTEGO
VAUXHALL
FIRENZA, VICTOR, VIVA, VX |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Connecting thread 17-M17
Number of mounting bores 2
Plug Type ID B+D+
Pulleys without belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
|
| |
FORD
GALAXY
SEAT
ALHAMBRA, ALHAMBRA VAN, CORDOBA, IBIZA, INCA, TOLEDO
VOLVO
S70, V70
VW
CADDY, GOLF, PASSAT, POLO, SHARAN, SHARAN Box Body/MPV, VENTO |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 120
Belt Pulley Ø [mm] 50
Distance from belt pulley to alternator [mm] 49
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+D+DF
Pulleys with freewheel belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 530 037
HITACHI
LR110 0502, LR1100-502A, LR1100-502B, LR1100-502C, LR1100-502E, LR1100-502F, LR1100-502G, LR1100-502H, LR1100-502J, LR1100-502K, LR1100-502L, LR1100-502N, LR1100-504B, LR1100-504C, LR1100-504E, LR110 0505, LR1100-505B
HONDA
31100-PLZ-D00
ISUZU
8-97189-113-0, 8-97189-113-3, 8-97189-113-4, 8-97189-113-5, 8-97189-113-6, 8-97189-113-7, 8-97189-113-8, 8-97326-180-1, 8-98056-867-0
OPEL
12 04 158, 62 04 140, 93 175 799, 93 175 944, 95 12 785, 97 189 113 |
| |
|
| |
CHEVROLET
CORSA
HONDA
CIVIC
OPEL
ASTRA, ASTRA CLASSIC, COMBO, CORSA, MERIVA
VAUXHALL
ASTRA, ASTRAVAN, COMBO, COMBO TOUR Mk II, CORSA, CORSAVAN, MERIVA |
| |
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 100
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 60
Distance from belt pulley to alternator [mm] 44
Number of grooves 6
Number of mounting bores 2
Plug Type ID B+L+W
Pulleys with v-ribbed belt pulley
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 030 072
HITACHI
LR17-0420, LR170 420B, LR170-427, LR170-427B, LR170-427C
ISUZU
8-97041-790-0
OPEL
12 04 144, 62 04 059, 90 542 407, 91 63 941, 95 12 124, 97 041 790 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 83
Belts Without V-belt
Distance from belt pulley to alternator [mm] 41
Number of grooves 1
Number of mounting bores 2
Plug Type ID B+SLNIG
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
|
| ERA p/n |
OE / Other p/n |
Used in vehicles |
|
|
|
|
ERA
|
| |
GENERAL MOTORS
R1 030 093
HITACHI
LR17-0505, LR170 505A, LR170 505B, LR170 505C, LR170 505D, LR170 505E, LR17-0511, LR170 511A, LR170 511B
ISUZU
8-97150-200-0, 8-97150-200-1, 8-97241-021-0
OPEL
62 04 042, 62 04 046, 62 04 106, 90 371 767, 90 371 769, 95 12 038, 97 150 200, 97 241 021 |
| |
|
|
|
|
|
|
|
| |
| |
Article Information
Alternator Charging Current [A] 70
Alternator Type incl. vacuum pump
Belt Pulley Ø [mm] 84
Belts Without V-belt
Distance from belt pulley to alternator [mm] 42
Number of grooves 1
Number of mounting bores 2
Plug Type ID B+L,W
Rotation Direction Clockwise rotation
Voltage [V] 14
|
|
| |
|
| |
|
| |
Original equipment numbers and pictures in this catalogue are used for reference purposes only
|
|
|
